When using an O-ring, the main design consideration is the corner or smallest radius (shown “r” in diagram). The inside radius should be at least three times the O-ring cross sectional diameter. In a perfect world, six times greater is even better. O-ring Gland Design Total Diametrical Clearance is the dif- ference between the bore diameter (A) and the plug diameter (H) dimensions. Tolerances of the bore and plug diameters determine the maximum and minimum diametrical clearance gap. These values divided by two will give the radial maximum and minimum clearance gaps. USA AS568 o-ring standard sizes are the most commonly used o-ring sizes in the world. Refer to our standard o-ring size chart to find USA AS568 o-ring dimensions. Order o-rings online from the world’s largest inventory network including custom o-rings typically without tooling fees.
Can O-rings be used in rectangular or non-circular groove patterns? This question comes up weekly, and the answer is a resounding “Yes!” however there are definite guidelines we want to follow. A non-circular face seal footprint might also be called a racetrack groove, a wandering groove or a custom plan view. When using an O-ring, the main design consideration is the corner or smallest radius (shown “r” in diagram). The inside radius should be at least three times the O-ring cross sectional diameter. In a perfect world, six times greater is even better. What we want to avoid is over-stressing the O-ring around the bend, or causing a corner crease which increases likelihood of corner leakage. Designing the radius at six times the cross section will minimize the bending stress, resulting in increased service life.
- Created Date: 1/13/2020 9:08:49 AM.
- O-Ring Groove Design Guides Expert Application Engineering Assistance. O-ring groove design guides offer default dimensional guidance on the most basic o-ring groove design applications. The best o-rings are useless without the right groove design which becomes increasingly important the more demanding the application environment.
Ideal design: r > 6 x W diameter but no less than r > 3 x W diameter
To minimize installation difficulties arising from stretch or OD compression on the seal, the centerline perimeter of the groove should match the centerline circumference of the O-ring. The rectangular cross section of the groove will follow the suggested guidelines in the O-Ring Handbook.
For those times when hardware real estate is at a premium and we simply cannot increase the inside corner radii to the desired size, an alternative option is the O-Seal. The O-Seal has a round cross section like an O-ring. However the footprint of the O-Seal is designed to match the shape of the groove. The primary advantage of the O-Seal is custom molding to fit the exact groove, eliminating the concern that comes with bending stress at the corners. A smaller corner radii can be used for the groove, allowing the footprint to fit perfectly within the application’s design constraints.
If there are multiple ports or openings on the face, or bolt holes to contour around, these seals can be consolidated into a single O-seal solution. By consolidating seals, the installation process becomes much easier. All seals are ready to be installed at the same time, and the risk of installing the incorrect seal material is eliminated. This may offer the added advantage of streamlining the bill of materials and simplifying the amount of stock to be replenished during the assembly process.
O-ring Groove Dimensions Static
O-Seals are available in nearly every material family and engineered for optimum size and configuration for each unique application. Parker Application Engineers are happy to assist you with your racetrack groove design or a custom O-Seal. Please contact us today via online chat or by email by visiting Parker O-Ring and Engineered Seals Division website.
This article was contributed by Dorothy Kern , applications engineer lead, O-Ring & Engineered Seals Division
Related content:
O Ring Slot Dimensions
O-ring groove design for non-circular groove
O Ring Groove Dimensions Imperial
O-ring groove design for non-circular groove
O Ring Groove Dimensions Roymech
I am designing a static seal with an o-ring.
The particularity is that the groove is non-circular. It has an oval-like shape (see picture in link below).
I am wondering how to calculate groove dimensions.
The medium is compressed air of 10 bar.
Pressure is on the inside, so the o-ring is pressed to the outermost groove wall.
I was thinking to calculate the groove the standard way as if the o-ring was placed in a circular groove, using some online calculator or the Parker Handbook.
Then, I would calculate my oval groove so that the outside wall ('outside circumference') of the oval groove has the same length as the outside wall of the circular groove.
Groove width and depth according to the standard calculations.
Would this be an acceptable calculation method?
Kind regards
Ray
